| Part Number |
Hose I.D. (in.) | Hose O.D. (in.) | Rated W.P. (psi) | Min. Burst (psi) | Min. Bend Radius (in.) | Wt. Per Ft. (lbs) | Recommended for | Tube | Reinforcement | WearGuard | Temperature | Recommended Couplings | L23 | S1 |
| A750-04 |
0 1/4 | 0.59 | 5500 | 22000 | 4 | 0.25 | High pressure hydraulic applications.Meets or exceeds DIN 20022-2SN performance specifications | Black, oil resistant, Nitrile (NBR) | Two wire braid of high tensile steel. | Black, oil and abrasion resistant Neoprene (CR). MSHA approved. | -40°F to 250°F | 1J, 1W, 1Y, Two-Piece | 0.750 | 0.260 |
| A750-06 |
0 3/8 | 0.75 | 5000 | 20000 | 5 | 0.32 | High pressure hydraulic applications.Meets or exceeds DIN 20022-2SN performance specifications | Black, oil resistant, Nitrile (NBR) | Two wire braid of high tensile steel. | Black, oil and abrasion resistant Neoprene (CR). MSHA approved. | -40°F to 250°F | 1J, 1W, 1Y, Two-Piece | 0.880 | 0.380 |
| A750-08 |
0 1/2 | 0.86 | 5000 | 20000 | 7 | 0.4 | High pressure hydraulic applications.Meets or exceeds DIN 20022-2SN performance specifications | Black, oil resistant, Nitrile (NBR) | Two wire braid of high tensile steel. | Black, oil and abrasion resistant Neoprene (CR). MSHA approved. | -40°F to 250°F | 1J, 1W, 1Y, Two-Piece | 0.880 | 0.380 |
| A750-10 |
0 5/8 | 1 | 3500 | 14000 | 8 | 0.49 | High pressure hydraulic applications.Meets or exceeds DIN 20022-2SN performance specifications | Black, oil resistant, Nitrile (NBR) | Two wire braid of high tensile steel. | Black, oil and abrasion resistant Neoprene (CR). MSHA approved. | -40°F to 250°F | 1J, 1W, 1Y, Two-Piece | 1.060 | 0.480 |
| A750-12 |
0 3/4 | 1.16 | 3000 | 12000 | 9.5 | 0.57 | High pressure hydraulic applications.Meets or exceeds DIN 20022-2SN performance specifications | Black, oil resistant, Nitrile (NBR) | Two wire braid of high tensile steel. | Black, oil and abrasion resistant Neoprene (CR). MSHA approved. | -40°F to 250°F | 1J, 1W, 1Y, Two-Piece | 1.060 | 0.480 |
| A750-16 |
1 | 1.49 | 2750 | 11000 | 12 | 0.9 | High pressure hydraulic applications.Meets or exceeds DIN 20022-2SN performance specifications | Black, oil resistant, Nitrile (NBR) | Two wire braid of high tensile steel. | Black, oil and abrasion resistant Neoprene (CR). MSHA approved. | -40°F to 250°F | 1J, 1W, 1Y, Two-Piece | 1.250 | 0.610 |
| 1750-20 |
1-1/4 | 1.9 | 1800 | 7200 | 16.5 | 1.47 | High pressure hydraulic applications.Meets or exceeds DIN 20022-2SN performance specifications | Black, oil resistant, Nitrile (NBR) | Two wire braid of high tensile steel. | Black, oil and abrasion resistant Neoprene (CR). MSHA approved. | -40°F to 250°F | 1J, 1W, 1Y, Two-Piece | 1.250 | 0.610 |
| 1750-24 |
1-1/2 | 2.15 | 1300 | 5200 | 25 | 1.7 | High pressure hydraulic applications.Meets or exceeds DIN 20022-2SN performance specifications | Black, oil resistant, Nitrile (NBR) | Two wire braid of high tensile steel. | Black, oil and abrasion resistant Neoprene (CR). MSHA approved. | -40°F to 250°F | 1J, 1W, 1Y, Two-Piece | 1.250 | 0.610 |
| 1750-32 |
2 | 2.68 | 1160 | 4640 | 25 | 2.34 | High pressure hydraulic applications.Meets or exceeds DIN 20022-2SN performance specifications | Black, oil resistant, Nitrile (NBR) | Two wire braid of high tensile steel. | Black, oil and abrasion resistant Neoprene (CR). MSHA approved. | -40°F to 250°F | 1J, 1W, 1Y, Two-Piece | 1.500 | 0.810 |
