| Part Number |
Hose I.D. (in.) | Hose O.D. (in.) | Rated W.P. (psi) | Min. Burst (psi) | Min. Bend Radius (in.) | Wt. Per Ft. (lbs) | Recommended for | Tube | Reinforcement | WearGuard | Temperature | Recommended Couplings | H2 | L20 | L38 | S | S4 |
| A101-03 |
0 3/16 | 0.47 | 3000 | 12000 | 3.5 | 0.13 | High pressure hydraulic oil lines. Meets or exceeds requirements of SAE 100R1 | Black, oil resistant, Nitrile (NBR) | One braid of high tensile steel wire | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -40°F to +250°F | 1P, 1J, Two-Piece | - | 0.330 | 0.370 | 0.810 | - |
| A101-04 |
0 1/4 | 0.53 | 2750 | 11000 | 4 | 0.16 | High pressure hydraulic oil lines. Meets or exceeds requirements of SAE 100R1 | Black, oil resistant, Nitrile (NBR) | One braid of high tensile steel wire | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -40°F to +250°F | 1P, 1J, Two-Piece | - | 0.390 | 0.470 | 0.940 | - |
| A101-05 |
0 5/16 | 0.59 | 2500 | 10000 | 4.5 | 0.17 | High pressure hydraulic oil lines. Meets or exceeds requirements of SAE 100R1 | Black, oil resistant, Nitrile (NBR) | One braid of high tensile steel wire | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -40°F to +250°F | 1P, 1J, Two-Piece | - | 0.490 | 0.470 | 1.130 | - |
| A101-06 |
0 3/8 | 0.68 | 2250 | 9000 | 5 | 0.22 | High pressure hydraulic oil lines. Meets or exceeds requirements of SAE 100R1 | Black, oil resistant, Nitrile (NBR) | One braid of high tensile steel wire | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -40°F to +250°F | 1P, 1J, Two-Piece | - | 0.540 | 0.530 | 1.380 | - |
| A101-08 |
0 1/2 | 0.8 | 2000 | 8000 | 7 | 0.28 | High pressure hydraulic oil lines. Meets or exceeds requirements of SAE 100R1 | Black, oil resistant, Nitrile (NBR) | One braid of high tensile steel wire | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -40°F to +250°F | 1P, 1J, Two-Piece | - | 0.530 | 0.590 | 1.630 | - |
| A101-10 |
0 5/8 | 0.93 | 1500 | 6000 | 8 | 0.34 | High pressure hydraulic oil lines. Meets or exceeds requirements of SAE 100R1 | Black, oil resistant, Nitrile (NBR) | One braid of high tensile steel wire | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -40°F to +250°F | 1P, 1J, Two-Piece | - | 0.530 | 0.590 | 1.880 | - |
| A101-12 |
0 3/4 | 1.09 | 1250 | 5000 | 9.5 | 0.41 | High pressure hydraulic oil lines. Meets or exceeds requirements of SAE 100R1 | Black, oil resistant, Nitrile (NBR) | One braid of high tensile steel wire | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -40°F to +250°F | 1P, 1J, Two-Piece | - | 0.530 | 0.590 | 2.250 | - |
| A101-16 |
1 | 1.41 | 1000 | 4000 | 12 | 0.63 | High pressure hydraulic oil lines. Meets or exceeds requirements of SAE 100R1 | Black, oil resistant, Nitrile (NBR) | One braid of high tensile steel wire | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -40°F to +250°F | 1P, 1J, Two-Piece | - | - | - | - | - |
| 1101-20 |
1-1/4 | 1.72 | 625 | 2500 | 16.5 | 0.91 | High pressure hydraulic oil lines. Meets or exceeds requirements of SAE 100R1 | Black, oil resistant, Nitrile (NBR) | One braid of high tensile steel wire | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -40°F to +250°F | 1P, 1J, Two-Piece | 0.270 | - | - | - | 0.810 |
| 1101-24 |
1-1/2 | 2 | 500 | 2000 | 20 | 1.07 | High pressure hydraulic oil lines. Meets or exceeds requirements of SAE 100R1 | Black, oil resistant, Nitrile (NBR) | One braid of high tensile steel wire | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -40°F to +250°F | 1P, 1J, Two-Piece | 0.310 | - | - | - | 1.000 |
| 1101-32 |
2 | 2.54 | 375 | 1500 | 25 | 1.44 | High pressure hydraulic oil lines. Meets or exceeds requirements of SAE 100R1 | Black, oil resistant, Nitrile (NBR) | One braid of high tensile steel wire | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -40°F to +250°F | 1P, 1J, Two-Piece | 0.350 | - | - | - | 1.130 |
