| Part Number |
Hose I.D. (in.) | Hose O.D. (in.) | Rated W.P. (psi) | Min. Burst (psi) | Min. Bend Radius (in.) | Wt. Per Ft. (lbs) | Recommended for | Tube | Reinforcement | WearGuard | Temperature | Recommended Couplings | H2 | L22 | S3 | S4 |
| A151-04 |
0 1/4 | 0.53 | 3000 | 12000 | 2 | 0.16 | Applications which meet or exceed SAE 100R17. Medium pressure hydraulic oil lines | Black, oil resistant, Nitrile (NBR) | One wire high tensile steel braid in sizes 1/4 through 1/2". Two wire high tensile steel braid in sizes 5/8-1". | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -40°F to +250°F | 1J, 1W, 1Y, Two-Piece | - | 0.540 | 1.880 | - |
| A151-06 |
0 3/8 | 0.68 | 3000 | 12000 | 2.5 | 0.23 | Applications which meet or exceed SAE 100R17. Medium pressure hydraulic oil lines | Black, oil resistant, Nitrile (NBR) | One wire high tensile steel braid in sizes 1/4 through 1/2". Two wire high tensile steel braid in sizes 5/8-1". | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -40°F to +250°F | 1J, 1W, 1Y, Two-Piece | - | 0.540 | 2.130 | - |
| A151-08 |
0 1/2 | 0.8 | 3000 | 12000 | 3.5 | 0.28 | Applications which meet or exceed SAE 100R17. Medium pressure hydraulic oil lines | Black, oil resistant, Nitrile (NBR) | One wire high tensile steel braid in sizes 1/4 through 1/2". Two wire high tensile steel braid in sizes 5/8-1". | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -40°F to +250°F | 1J, 1W, 1Y, Two-Piece | - | - | - | - |
| A151-10 |
0 5/8 | 1 | 3000 | 12000 | 4 | 0.49 | Applications which meet or exceed SAE 100R17. Medium pressure hydraulic oil lines | Black, oil resistant, Nitrile (NBR) | One wire high tensile steel braid in sizes 1/4 through 1/2". Two wire high tensile steel braid in sizes 5/8-1". | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -40°F to +250°F | 1J, 1W, 1Y, Two-Piece | 0.580 | - | - | 0.690 |
| A151-12 |
0 3/4 | 1.16 | 3000 | 12000 | 4.75 | 0.57 | Applications which meet or exceed SAE 100R17. Medium pressure hydraulic oil lines | Black, oil resistant, Nitrile (NBR) | One wire high tensile steel braid in sizes 1/4 through 1/2". Two wire high tensile steel braid in sizes 5/8-1". | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -40°F to +250°F | 1J, 1W, 1Y, Two-Piece | 0.670 | - | - | 0.810 |
| A151-16 |
1 | 1.49 | 3000 | 12000 | 6 | 0.9 | Applications which meet or exceed SAE 100R17. Medium pressure hydraulic oil lines | Black, oil resistant, Nitrile (NBR) | One wire high tensile steel braid in sizes 1/4 through 1/2". Two wire high tensile steel braid in sizes 5/8-1". | Black, oil and abrasion resistant Neoprene (CR). MSHA approved | -40°F to +250°F | 1J, 1W, 1Y, Two-Piece | 0.830 | - | - | 0.940 |
