| Part Number |
Hose I.D. (in.) | Hose O.D. (in.) | Rated W.P. (psi) | Min. Burst (psi) | Min. Bend Radius (in.) | Wt. Per Ft. (lbs) | Recommended for | Tube | Reinforcement | Cover | Temperature | Recommended Couplings | Lengths | Premium Features | Din Tube O.D. (MM) | Tube Nut Part Number | Sleeve Part Number | D2 | L12 | M1 | N1 | N2 | S2 | NPTF |
| 1212-06CR |
0.375 | 0.797 | 4000 | 16000 | 2.5 | 0.4 | High pressure hydraulic oil lines for heavy duty service applications with crude oils, fuel oils, lubricating oils, and gasoline. Exceeds SAE 100R12 performance and half bend radius. | Black, oil resistant, Neoprene (CR) | Four plies of spirally-wrapped high tensile steel wire | Black, ultra high abrasion compound which is weather and oil resistant. MSHA approved. Yellow mylar layline. | -40°F to +250°F | 1W, 1Y, Two-Piece | Hose supplied in random lengths | 1. Ultra high abrasion resistant cover 2. Half bend radius flexibility 3. High impulse life | 8 | 9201-L-8 | 9202-L-8 | - | - | 1.640 | 1.360 | - | 1.440 | 3/4-14 |
| 1212-08CR |
0.500 | 0.935 | 4000 | 16000 | 3.5 | 0.54 | High pressure hydraulic oil lines for heavy duty service applications with crude oils, fuel oils, lubricating oils, and gasoline. Exceeds SAE 100R12 performance and half bend radius. | Black, oil resistant, Neoprene (CR) | Four plies of spirally-wrapped high tensile steel wire | Black, ultra high abrasion compound which is weather and oil resistant. MSHA approved. Yellow mylar layline. | -40°F to +250°F | 1W, 1Y, Two-Piece | Hose supplied in random lengths | 1. Ultra high abrasion resistant cover 2. Half bend radius flexibility 3. High impulse life | 10 | 9201-L-10 | 9202-L-10 | - | - | 1.760 | 1.620 | - | 1.630 | 1 - 11-1/2 |
| 1212-10CR |
0.625 | 1.08 | 4000 | 16000 | 4 | 0.74 | High pressure hydraulic oil lines for heavy duty service applications with crude oils, fuel oils, lubricating oils, and gasoline. Exceeds SAE 100R12 performance and half bend radius. | Black, oil resistant, Neoprene (CR) | Four plies of spirally-wrapped high tensile steel wire | Black, ultra high abrasion compound which is weather and oil resistant. MSHA approved. Yellow mylar layline. | -40°F to +250°F | 1W, 1Y, Two-Piece | Hose supplied in random lengths | 1. Ultra high abrasion resistant cover 2. Half bend radius flexibility 3. High impulse life | 12 | 9201-L-12 | 9202-L-12 | - | - | 1.920 | 1.700 | - | 1.880 | 1-1/4 - 11-1/2 |
| 1212-12CR |
0.750 | 1.21 | 4000 | 16000 | 4.75 | 0.94 | High pressure hydraulic oil lines for heavy duty service applications with crude oils, fuel oils, lubricating oils, and gasoline. Exceeds SAE 100R12 performance and half bend radius. | Black, oil resistant, Neoprene (CR) | Four plies of spirally-wrapped high tensile steel wire | Black, ultra high abrasion compound which is weather and oil resistant. MSHA approved. Yellow mylarlayline. | -40°F to +250°F | 1W, 1Y, Two-Piece | Hose supplied in random lengths | 1. Ultra high abrasion resistant cover 2. Half bend radius flexibility 3. High impulse life | 15 | 9201-L-15 | 9202-L-15 | - | - | - | - | - | - | - |
| 1212-16CR |
1 | 1.495 | 4000 | 16000 | 6 | 1.34 | High pressure hydraulic oil lines for heavy duty service applications with crude oils, fuel oils, lubricating oils, and gasoline. Exceeds SAE 100R12 performance and half bend radius. | Black, oil resistant, Neoprene (CR) | Four plies of spirally-wrapped high tensile steel wire | Black, ultra high abrasion compound which is weather and oil resistant. MSHA approved. Yellow mylarlayline. | -40°F to +250°F | 1W, 1Y, Two-Piece | Hose supplied in random lengths | 1. Ultra high abrasion resistant cover 2. Half bend radius flexibility 3. High impulse life | 18 | 9201-L-18 | 9202-L-18 | 0.190 | 0.630 | - | - | 0.640 | 0.550 | 1/8-27 |
| 1212-20CR |
1-1/4 | 1.85 | 3000 | 12000 | 8.25 | 1.74 | High pressure hydraulic oil lines for heavy duty service applications with crude oils, fuel oils, lubricating oils, and gasoline. Exceeds SAE 100R12 performance and half bend radius. | Black, oil resistant, Neoprene (CR) | Four plies of spirally-wrapped high tensile steel wire | Black, ultra high abrasion compound which is weather and oil resistant. MSHA approved. Yellow mylarlayline. | -40°F to +250°F | 1W, 1Y, Two-Piece | Hose supplied in random lengths | 1. Ultra high abrasion resistant cover 2. Half bend radius flexibility 3. High impulse life | 22 | 9201-L-22 | 9202-L-22 | 0.280 | 0.680 | - | - | 0.860 | 0.550 | 1/4-18 |
| 1212-24CR |
1-1/2 | 2.105 | 2500 | 10000 | 10 | 2.01 | High pressure hydraulic oil lines for heavy duty service applications with crude oils, fuel oils, lubricating oils, and gasoline. Exceeds SAE 100R12 performance and half bend radius. | Black, oil resistant, Neoprene (CR) | Four plies of spirally-wrapped high tensile steel wire | Black, ultra high abrasion compound which is weather and oil resistant. MSHA approved. Yellow mylar layline. | -40°F to +250°F | 1W, 1Y, Two-Piece | Hose supplied in random lengths | 1. Ultra high abrasion resistant cover 2. Half bend radius flexibility 3. High impulse life | 28 | 9201-L-28 | 9202-L-28 | 0.410 | 0.680 | - | - | 0.950 | 0.750 | 3/8-18 |
| 1212-32CR |
2 | 2.626 | 2500 | 10000 | 12.5 | 2.75 | High pressure hydraulic oil lines for heavy duty service applications with crude oils, fuel oils, lubricating oils, and gasoline. Exceeds SAE 100R12 performance and half bend radius. | Black, oil resistant, Neoprene (CR) | Four plies of spirally-wrapped high tensile steel wire | Black, ultra high abrasion compound which is weather and oil resistant. MSHA approved. Yellow mylar layline. | -40°F to +250°F | 1W, 1Y, Two-Piece | Hose supplied in random lengths | 1. Ultra high abrasion resistant cover 2. Half bend radius flexibility 3. High impulse life | 35 | 9201-L-35 | 9202-L-35 | 0.280 | 0.740 | - | - | 0.860 | 0.750 | 1/4-18 |
