| Part Number |
Hose I.D. (in.) | Hose O.D. (in.) | Rated W.P. (psi) | Min. Burst (psi) | Min. Bend Radius (in.) | Wt. Per Ft. (lbs) | Recommended for | Tube | Reinforcement | Cover | Temperature | Recommended Couplings | Din Tube O.D. (MM) | Tube Nut Part Number | Sleeve Part Number | D2 | L12 | N2 | S2 | NPTF |
| 1312-06 |
0.375 | 0.8 | 4000 | 16000 | 5 | 0.44 | High pressure hydraulic oil lines for heavy duty service applications with crude oils, fuel oils, lubricating oils, and gasoline. Meets or exceeds SAE 100R12. | Black, oil resistant, Neoprene (CR) | Four plies of spirally-wrapped high tensile steel wire | A synthetic rubber which is weather and temperature resistant. MSHA approved. Yellow mylar layline | -40°F to +250°F | 1W, 1Y, Two-Piece | - | - | - | 0.530 | 0.740 | 1.170 | 0.870 | 1/2-14 |
| 1312-08 |
0.500 | 0.94 | 4000 | 16000 | 7 | 0.55 | High pressure hydraulic oil lines for heavy duty service applications with crude oils, fuel oils, lubricating oils, and gasoline. Meets or exceeds SAE 100R12. | Black, oil resistant, Neoprene (CR) | Four plies of spirally-wrapped high tensile steel wire | A synthetic rubber which is weather and temperature resistant. MSHA approved. Yellow mylar layline | -40°F to +250°F | 1W, 1Y, Two-Piece | 6 | 9201-H-6 | 9202-H-6 | 0.410 | 0.800 | 0.950 | 0.750 | 3/8-18 |
| 1312-10 |
0.625 | 1.08 | 4000 | 16000 | 8 | 0.77 | High pressure hydraulic oil lines for heavy duty service applications with crude oils, fuel oils, lubricating oils, and gasoline. Meets or exceeds SAE 100R12. | Black, oil resistant, Neoprene (CR) | Four plies of spirally-wrapped high tensile steel wire | A synthetic rubber which is weather and temperature resistant. MSHA approved. Yellow mylar layline | -40°F to +250°F | 1W, 1Y, Two-Piece | 8 | 9201-H-8 | 9202-H-8 | 0.530 | 0.800 | 1.170 | 0.750 | 1/2-14 |
| 1312-12 |
0.750 | 1.21 | 4000 | 16000 | 9.5 | 0.82 | High pressure hydraulic oil lines for heavy duty service applications with crude oils, fuel oils, lubricating oils, and gasoline. Meets or exceeds SAE 100R12. | Black, oil resistant, Neoprene (CR) | Four plies of spirally-wrapped high tensile steel wire | A synthetic rubber which is weather and temperature resistant. MSHA approved. Yellow mylar layline | -40°F to +250°F | 1W, 1Y, Two-Piece | 10 | 9201-H-10 | 9202-H-10 | 0.530 | 0.920 | 1.170 | 1.060 | 1/2-14 |
| 1312-16 |
1 | 1.5 | 4000 | 16000 | 12 | 1.28 | High pressure hydraulic oil lines for heavy duty service applications with crude oils, fuel oils, lubricating oils, and gasoline. Meets or exceeds SAE 100R12. | Black, oil resistant, Neoprene (CR) | Four plies of spirally-wrapped high tensile steel wire | A synthetic rubber which is weather and temperature resistant. MSHA approved. Yellow mylar layline | -40°F to +250°F | 1W, 1Y, Two-Piece | 12 | 9201-H-12 | 9202-H-12 | 0.720 | 1.020 | 1.300 | 1.180 | 3/4-14 |
| 1312-20 |
1-1/4 | 1.85 | 3000 | 12000 | 16.5 | 1.76 | High pressure hydraulic oil lines for heavy duty service applications with crude oils, fuel oils, lubricating oils, and gasoline. Meets or exceeds SAE 100R12. | Black, oil resistant, Neoprene (CR) | Four plies of spirally-wrapped high tensile steel wire | A synthetic rubber which is weather and temperature resistant. MSHA approved. Yellow mylar layline | -40°F to +250°F | 1W, 1Y, Two-Piece | 14 | 9201-H-14 | 9202-H-14 | 0.940 | 1.020 | 1.480 | 1.420 | 1 - 11-1/2 |
| 1312-24 |
1-1/2 | 2.1 | 2500 | 10000 | 20 | 2.18 | High pressure hydraulic oil lines for heavy duty service applications with crude oils, fuel oils, lubricating oils, and gasoline. Meets or exceeds SAE 100R12. | Black, oil resistant, Neoprene (CR) | Four plies of spirally-wrapped high tensile steel wire | A synthetic rubber which is weather and temperature resistant. MSHA approved. Yellow mylar layline | -40°F to +250°F | 1W, 1Y, Two-Piece | 16 | 9201-H-16 | 9202-H-16 | 0.720 | 1.180 | 1.300 | 1.420 | 3/4-14 |
| 1312-32 |
2 | 2.62 | 2500 | 10000 | 25 | 2.85 | High pressure hydraulic oil lines for heavy duty service applications with crude oils, fuel oils, lubricating oils, and gasoline. Meets or exceeds SAE 100R12. | Black, oil resistant, Neoprene (CR) | Four plies of spirally-wrapped high tensile steel wire | A synthetic rubber which is weather and temperature resistant. MSHA approved. Yellow mylar layline | -40°F to +250°F | 1W, 1Y, Two-Piece | 20 | 9201-H-20 | 9202-H-20 | 0.940 | 1.180 | 1.480 | 1.420 | 1 - 11-1/2 |
