| Part Number |
Hose I.D. (in.) | Hose O.D. (in.) | Rated W.P. (psi) | Min. Burst (psi) | Min. Bend Radius (in.) | Wt. Per Ft. (lbs) | Rated Suction (in./hg.) | Recommended for | Tube | Reinforcement | Cover | Temperature | Branding | D2 | S1 | NPTF |
| 2014-12 |
3/4 | 1.2 | 300 | 1200 | 2.5 | 0.4 | 25.0 | Petroleum and water based hydraulic fluids, in low pressure and return line service. Minimum bend radius one half the bend radius of SAE 100R4. | Black, oil resistant, Nitrile (NBR) | Two textile braids, pre-treated for tube and cover adhesion. Helix wires are located between the braids to resist collapse under vacuum or bending. | Black, oil and weather resistant Neoprene (CR). MSHA approved. | -40°F to +212°F | Green Mylar "NRP Superflex Return Line" | 0.610 | 1.380 | 1 - 11-1/2 |
| 2014-16 |
1 | 1.49 | 250 | 1000 | 3 | 0.54 | 25.0 | Petroleum and water based hydraulic fluids, in low pressure and return line service. Minimum bend radius one half the bend radius of SAE 100R4. | Black, oil resistant, Nitrile (NBR) | Two textile braids, pre-treated for tube and cover adhesion. Helix wires are located between the braids to resist collapse under vacuum or bending. | Black, oil and weather resistant Neoprene (CR). MSHA approved. | -40°F to +212°F | Green Mylar "NRP Superflex Return Line" | 0.720 | 1.500 | 3/4-14 |
| 2014-20 |
1-1/4 | 1.78 | 200 | 800 | 4 | 0.66 | 25.0 | Petroleum and water based hydraulic fluids, in low pressure and return line service. Minimum bend radius one half the bend radius of SAE 100R4. | Black, oil resistant, Nitrile (NBR) | Two textile braids, pre-treated for tube and cover adhesion. Helix wires are located between the braids to resist collapse under vacuum or bending. | Black, oil and weather resistant Neoprene (CR). MSHA approved. | -40°F to +212°F | Green Mylar "NRP Superflex Return Line" | 0.810 | 1.500 | 1 - 11-1/2 |
| 2014-24 |
1-1/2 | 2.06 | 150 | 600 | 5 | 0.87 | 25.0 | Petroleum and water based hydraulic fluids, in low pressure and return line service. Minimum bend radius one half the bend radius of SAE 100R4. | Black, oil resistant, Nitrile (NBR) | Two textile braids, pre-treated for tube and cover adhesion. Helix wires are located between the braids to resist collapse under vacuum or bending. | Black, oil and weather resistant Neoprene (CR). MSHA approved. | -40°F to +212°F | Green Mylar "NRP Superflex Return Line" | 0.940 | 1.750 | 1 - 11-1/2 |
| 2014-32 |
2 | 2.54 | 100 | 400 | 6 | 1.36 | 25.0 | Petroleum and water based hydraulic fluids, in low pressure and return line service. Minimum bend radius one half the bend radius of SAE 100R4. | Black, oil resistant, Nitrile (NBR) | Two textile braids, pre-treated for tube and cover adhesion. Helix wires are located between the braids to resist collapse under vacuum or bending. | Black, oil and weather resistant Neoprene (CR). MSHA approved. | -40°F to +212°F | Green Mylar "NRP Superflex Return Line" | 1.020 | 1.880 | 1-1/4 - 11-1/2 |
| 2014-40 |
2-1/2 | 3.02 | 62 | 250 | 7 | 1.72 | 25.0 | Petroleum and water based hydraulic fluids, in low pressure and return line service. Minimum bend radius one half the bend radius of SAE 100R4. | Black, oil resistant, Nitrile (NBR) | Two textile braids, pre-treated for tube and cover adhesion. Helix wires are located between the braids to resist collapse under vacuum or bending. | Black, oil and weather resistant Neoprene (CR). MSHA approved. | -40°F to +212°F | Green Mylar "NRP Superflex Return Line" | 1.260 | 2.130 | 1-1/2 - 11-1/2 |
