| Part Number |
Hose I.D. (in.) | Hose O.D. (in.) | Rated W.P. (psi) | Min. Bend Radius (in.) | Wt. Per Ft. (lbs) | Test Pressure (PSI) | Cplg Wt. | API Thread (in.) | Application | Tube | Reinforcement | Cover | Temperature | Branding | Lengths | Premium Features |
| 5501-40 |
2-1/2 | 4.32 | 4,000 | 48 | 12.9 | 6,000 | 54 | 3 | Oil field drilling and exploration at API Grade “C†working pressures; where a heavy duty long service life hose is required | Black, oil and abrasion resistant Nitrile (NBR). Suitable for oil or water based muds | Multiple plies of bias laid nylon cord for extra strength and flexibility. Two spirally wound, high tensile, multiple strand cable | Black, oil, weather and abrasion resistant Neoprene (CR) | -4 to 212°F | NRP POWERFLEX SILVER STRIPE ROTARY 3 INCH I.D. GRADE C 8,000 PSI TEST 4,000 MAX. WP MADE IN USA | 4 ft. to 100 ft | Abrasion, oil and weather resistant. Swaged on fittings for longer service life. Continuous brand for easy identification |
| 5501-48 |
3 | 4.82 | 4,000 | 48 | 14.9 | 6,000 | 74 | 4 | Oil field drilling and exploration at API Grade “C†working pressures; where a heavy duty long service life hose is required | Black, oil and abrasion resistant Nitrile (NBR). Suitable for oil or water based muds | Multiple plies of bias laid nylon cord for extra strength and flexibility. Two spirally wound, high tensile, multiple strand cable | Black, oil, weather and abrasion resistant Neoprene (CR) | -4 to 212°F | NRP POWERFLEX SILVER STRIPE ROTARY 3 INCH I.D. GRADE C 8,000 PSI TEST 4,000 MAX. WP MADE IN USA | 4 ft. to 100 ft | Abrasion, oil and weather resistant. Swaged on fittings for longer service life. Continuous brand for easy identification |
| 5501-56 |
3-1/2 | 5.32 | 4,000 | 54 | 16.6 | 6,000 | 94 | 4 | Oil field drilling and exploration at API Grade “C†working pressures; where a heavy duty long service life hose is required | Black, oil and abrasion resistant Nitrile (NBR). Suitable for oil or water based muds | Multiple plies of bias laid nylon cord for extra strength and flexibility. Two spirally wound, high tensile, multiple strand cable | Black, oil, weather and abrasion resistant Neoprene (CR) | -4 to 212°F | NRP POWERFLEX SILVER STRIPE ROTARY 3 INCH I.D. GRADE C 8,000 PSI TEST 4,000 MAX. WP MADE IN USA | 4 ft. to 100 ft | Abrasion, oil and weather resistant. Swaged on fittings for longer service life. Continuous brand for easy identification |
